When the Slab Itself Is Sinking
Slab piers reach through the concrete you walk on and stand it on soil deep enough to ignore the drought and rain cycles that let it drop.
Let's take the first step toward solid ground.
A local specialist will evaluate your foundation, walk you through the findings, and send a clear estimate. No cost, no pressure.
What to know about slab piers, and when it's the right call.
A slab pier turns the floor itself into a supported structure. The crew cores an opening through the concrete at each planned location and installs a steel pier beneath it, screwed in under logged torque, the twisting force recorded as proof of capacity, for helical piers or driven hydraulically for push piers, advancing until the readings prove the pier has reached soil that can carry its share of the load. A bracket assembly then connects the underside of the slab to the pier head. With every pier verified, the crew lifts the slab toward its original elevation, watching crack lines close and door gaps even out as it rises, then locks the connections so the slab bears on the steel. The result is a floor standing on strata far below the moisture swings of the surface clay. The cored openings are patched with concrete, leaving small, tidy circles instead of trenches through your home.
The symptoms that usually lead to slab piers are on the foundation repair problem signs page, alongside the other signs that point to the same underlying cause.
How we install slab piers.
Free evaluation with elevation mapping
We measure floor elevations across the slab to map where it has dropped and how far, and separate deep settlement that needs piers from shallow voids that polyurethane lifting can solve.
Pier layout
Pier locations are planned from the elevation map so the lift is even and the loads are shared, with pier type matched to the soil and access.
Core and install
Small openings are cored through the slab, and each pier is driven or screwed beneath the floor until its readings verify capacity in stable soil.
Lift and lock
The slab is raised toward level while the crew tracks elevations in real time, then locked to the pier heads so it bears on the steel.
Patch and verify
Cored openings are patched flush, the site is cleaned, and final elevations are compared against the starting map so you can see the correction.
The slab comes back up.
Sunken concrete almost never means bad concrete. The soil under it washed out or compacted, and the slab followed. Filling that void lifts the slab back to where it was poured.
Slab Piers on a real project.
Slab piers reach through the concrete you walk on and stand it on soil deep enough to ignore the drought and rain cycles that let it drop.
Care and expertise from a team that's been doing this since 2011.
When the fix is slab piers, the installer matters as much as the method. Dalinghaus crews handle foundation, concrete, and crawl space work across California, Arizona, and Nevada, and nothing else.
Foundation repair, concrete leveling, and crawl space repair are our entire focus. Not a sideline.
More than 2,000 projects on the clay and desert soils of California, Arizona, and Nevada since 2011.
CSLB License #983851 in California, ROC #330307 in Arizona, and License #0089738 in Nevada. Look us up with the state before we ever set foot on your property.
Warranty terms come in writing with every proposal, and the terms that apply to your job are stated in that job's paperwork. Ask your project specialist during the free evaluation.
Answers to common questions about Slab Piers.
Don't see your question here? Our team is happy to help. Reach out anytime.
It depends on how deep the problem goes. Shallow voids and modest settlement usually respond to polyurethane lifting, which is faster and less invasive. Deep seated settlement, where the soil has failed well below the slab, needs piers that reach past it entirely. The elevation map from the free evaluation tells us which one your floor is dealing with, and we recommend the smaller fix whenever it will hold.
